Studer D950 User Manual

D950 Digital Mixing System
3-40 Desk Operation SW V3.3 Date printed: 03.09.03
3.3.7.4 EQ 2 Mode Parameters on the LACP
Example EQ2 Mode, General Page:
Available operating elements and their function
PHASE
Display
=
Indication of EQ selection
EQ_2; EQ2 mode general page (page 1)
EQ_F; EQ2 mode frequency setting page (page 2)
EQ_Q; EQ2 mode Q setting page (page 3)
EQ_G; EQ2 mode gain setting page (page 4)
EQ2 mode control parameter
Last used HI band frequency
indication, HI band gain
Last used HM band frequency
indication, HM band gain
SW key
Rotary encoder
LED bar
Center LED
Display
=
=
=
=
=
Band ON/OFF (key is illuminated when ON)
Gain (boost/cut) adjustment
Dot display, indicates gain setting
On if gain = 0 dB (no boost/cut)
141; frequency in Hz
2k51; frequency in kHz
AUTO
SW
1
AUTO
SW
2
AUTO
SW
3
AUTO
SW
4
n–1
TALK21
LAST MODE43
PAGE
FREEZE
EQ 2
2k51
2k51
2k51
2k51
SW key
Rotary encoder
LED bar
Center LED
Display
=
=
=
=
=
Band ON/OFF (key is illuminated when ON)
Gain (boost/cut) adjustment
Dot display, indicates gain setting
On if gain = 0 dB (no boost/cut)
141; frequency in Hz
2k51; frequency in kHz
Last used LO band frequency
indication, LO band gain
SW key
Rotary encoder
LED bar
Center LED
Display
=
=
=
=
=
Band ON/OFF (key is illuminated when ON)
Gain (boost/cut) adjustment
Dot display, indicates gain setting
On if gain = 0 dB (no boost/cut)
141; frequency in Hz
2k51; frequency in kHz
Last used LM band frequency
indication, LM band gain
SW key
Rotary encoder
LED bar
Center LED
Display
=
=
=
=
=
Band ON/OFF (key is illuminated when ON)
Gain (boost/cut) adjustment
Dot display, indicates gain setting
On if gain = 0 dB (no boost/cut)
141; frequency in Hz
2k51; frequency in kHz
