D950/Vista7 Digital Mixing System
Date printed: 27.08.03 SW V3.3 AutoTouch+ 5-177
5.20 Auto Touch Plus Window
[1] Mix Tree window. Can be hidden by clicking on the “Hide Tree” button. If
hidden, this button turns into “Show Tree”, the “Display Mode” button be-
comes inactive (refer to chapter 5.4.1 for details).
[2] Several Mix Passes are shown in the Mix Tree window. With the “Display
Mode” button the display mode of the mix passes can be changed, and it
can be decided if only the Mix Pass number, only the Mix Pass name, or
both shall be displayed (refer to chapter 5.4.1.3 for details).
[3] Mix Pass Stack; holds up to eight Mix Passes for immediate use (e.g. di-
rect comparison of Mix Passes (refer to chapter 5.5.1 for details).
[4] Glide Time; defines the length of the glide. To enter a value just click in
the box and type the desired glide time, or use the right click menu allow-
ing e.g. to access the Cue list with timecode cue points (also refer to
chapter 5.9.3).
[5] Mix Protection allows individual controls or a group of controls to be
protected or locked-out from changes (also refer to chapter 5.13). If Mix
Protection is on, the yellow LED symbol is on.
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[15]
[17]
[18]
[14]
[16]
