Studer D950 User Manual

D950 Digital Mixing System
Date printed: 03.09.03 SW V3.3 Desk Operation 3-71
Example: Local Assignment
• Press ASN SEL on the Channel Strip; the ASN SEL key will flash.
The flashing ASN SEL key indicates Select Edit Mode.
• Press DLY on the Channel Strip to control the delay parameters.
3.3.12.2 Delay Parameters
The Delay value can only be adjusted as a delay time (displayed in sam-
ples or ms) using the rotary encoder within the fourth LACP section. As
the Delay time is adjusted, the distance display changes to show the corre-
sponding physical distance (displayed in centimeters and meters).
DELAY: Delay can be switched ON/OFF using the DLY key on the Channel Strip.
DELAY TIME: Delay time can be set in a range from 0 through 47 samples, and from 1 ms
through 100 ms (or, dependent upon the system configuration, to a maxi-
mum of 240 ms). While adjusting delay time, the value is simultaneously
converted into a delay distance (from 0 through 33.3 cm, and from 0.34
through 34 m, or up to 81.5 m, depending on the system configuration).
Both values are displayed simultaneously on the LACP.
DELAY DISTANCE: Delay distance (display only, no delay distance setting) in cm or m, see
DELAY TIME above.
PAN
OPT
DLY
INS
CMP/
LIM
EQ
3
ON
1
ON
3
ON
1
ON
4
ON
2
ON
4
ON
2
ON
AUX
MONO
GEN
IN 2
IN 1
INPUT DIR OUT
ON
Input
Busses
Meters
Out
PROCESSING
FILT
EXP/
GTE
DYN
ASN
SEL
Processing
USER
1
USER
2
AUX
STEREO
n–1
TALK
21
LAST MODE43
PAGE
FREEZE
n–1
TALK21
LAST MODE43
PAGE
FREEZE
n–1
TALK21
LAST MODE43
PAGE
FREEZE
n–1
TALK
21
LAST MODE43
PAGE
FREEZE
n–1
TALK21
LAST MODE43
PAGE
FREEZE
n–1
TALK21
LAST MODE43
PAGE
FREEZE
EQHI
EQHI EQHI
EQHI
DLAY EQHI
