Studer D950 User Manual

D950 Digital Mixing System
3-44 Desk Operation SW V3.3 Date printed: 03.09.03
3.3.8 Filter Section
On all Channel types, both a high- and a low-pass filter can be configured.
These filters can be switched ON/OFF on each Channel Strip.
In addition, a notch filter is available if the EQ with Notch Filter is in-
cluded in the channel configuration
Note: In addition, both filters can be switched ON/OFF individually. As a conse-
quence, the FILT key on the channel strip has no effect if both filters have
been switched OFF
3.3.8.1 Assigning the Filter Section
A. Global Assignment:
• Press FILTER on the Master Menu Selector.
The displays of all Channel Strips will switch over and indicate the
filter control parameters, except those in FREEZE mode; see chapter
3.3.2.
• Press one of the PAGE 1 through 3 keys on the MMS to select the de-
sired filter (PAGE 1 for HPF, PAGE 2 for LPF, PAGE 3 for NTCH if
configured).
B. Local Assignment on the channel strip:
• Press ASN SEL; the ASN SEL key will flash.
• Press the FILT key.
• Press one of the PAGE 1 through 3 keys on the Channel Strip to select
the desired filter (PAGE 1 for HPF, PAGE 2 for LPF, PAGE 3 for
NTCH if configured).
C. Local Assignment affecting all channel strips:
• Press LINK ACCESS on the Master Menu Selector.
• Pressing a local assignment key will now affect all Channel Strips. The
same functions as described in “B” are available.
D. Local Assignment with Auto Assign Modes "In-Only":
• Press AUTO ASSIGN MODES on the Master Menu Selector once
(AUTO ASSIGN MODES is illuminated).
• Pressing the FILT key on the channel strip will assign the FILTER pa-
rameters to the LACP without pressing the ASN SEL key, provided
the function toggles to an IN (or ON) status. If it toggles to an OUT (or
OFF) status, the knob status does not change.
CMP/
LIM
EQ
3
ON
1
ON
3
ON
1
ON
4
ON
2
ON
4
ON
2
ON
AUX
MONO
GEN
IN 2
IN 1
INPUT DIR OUT
ON
Input
Busses
Meters
Out
PROCESSING
FILT
EXP/
GTE
DYN
AUX
STEREO
MENU
EQ2
INPUT
OUT/
N-1
EQ FILTER
COMP GATE
EXP/LIM/
INSERT DELAY
MONO
AUX
ADD.
AUX
STEREO
AUX
PAN
PAGE
1
PAGE
3
SHOW
VALUES
FREEZE
OFF
LINK
ACCESS
MODES
ASSIGN
AUTO
4
PAGE
PAGE
2
