D950/Vista Digital Mixing System
4-64 GC Operation SW V3.3 Date printed: 05.08.03
The following is an example of the ways in which a D950 Desk with 16
Channel Strips may be assigned for two very different Session Configura-
tions:
Example #1:
Example #2:
Such a Strip Setup forms the starting point for using a new Session Con-
figuration, and can be adapted at any time (as shown below).
This powerful concept allows almost any D950 Desk to function with any
D950 Session Configuration (even if the console size is different) without
a problem.
Bank 1
Layer 1
Layer 2
AUX 1 AUX 2 AUX 3 AUX 4
In Mono 1 In Mono 2 In Mono 3 In Mono 4 In Mono 5 In Mono 6 In Mono 7 In Mono 8 In Mono 9 In Mono 10 In Mono 11 In Mono 12 Master 1 Master 2 Master 3 Master 4
Desk: 16 Strips
Session Config: 12 Mono inputs / 4 Mono masters / 4 Mono AUX
Assigned layers: Bank 1 / Layer 1 + Layer 2
other Banks & Layers not assigned
Bank 1
Layer 1
Layer 2
In Mono 1 In Mono 2 In Mono 3 In Mono 4 In Mono 5 In Mono 6 In Mono 7 In Mono 8 In Mono 9 In Mono 10 In Mono 11 In Mono 12 In Mono13 In Mono 14In Mono 15In Mono 16
In Mono 17 In Mono 18In Mono 19 In Mono 20 In Mono 21 In Mono 22 In Mono 23 In Mono 24 In Mono 25In Mono 26 In Mono 27 In Mono 28 In Mono 29In Mono 30 In Mono 31 In Mono 32
Bank 2
Layer 1
Layer 2
In Mono 33
In Mono 34In Mono 35In Mono 36 In Mono 37In Mono 38In Mono 39In Mono 40 In Mono 41In Mono 42In Mono 43In Mono 44 In Mono 45In Mono 46In Mono 47In Mono 48
AUX 1 AUX 2 AUX 3 AUX 4
Master 1 Master 2 Master 3 Master 4 Master 5 Master 6
In Stereo 1 In Stereo 2 In Stereo 3 In Stereo 4
Desk: 16 Strips
Session Config:
48 Mono inputs / 4 Stereo inputs / 6 Mono mast ers / 4 Mono AUX
Assigned layers: Bank 1 / Layer 1 + Layer 2
Bank 2 / Layer 1 + Layer 2
other Banks & Layers not assigned
