D950 Digital Mixing System
Date printed: 03.09.03 SW V3.3 Introduction 1-15
In this way, many combinations of AUX, Clean-feed, multitrack selection,
group and master busses can be configured. Since the available DSP power
is shared by the channels, busses, and I/O interfaces, there is no maximum
number of channels for a D950 console; this number is solely a function of
the installed DSP functionality.
Input & output
interfaces
Console DSP channels
(inputs, groups, AUXes,
masters ...)
100
200
400
800
100
200
max.
256 mono input channels, 24 output channels, 150 I/Os
128 mono input channels, 24 output channels, 48 Tracks, 350 I/Os
96 mono input channels, 16 output channels, 900 I/Os
All 3 configurations use the same DSP capacity
0
max.
