Studer D950 User Manual

D950/Vista Digital Mixing System
Date printed: 05.08.03 SW V3.3 GC Operation 4-105
Calibrate Mode: Calibrate mode allows setting a level offset for a whole monitor group
(MAIN, ALT or NEARFIELD) relative to the other two. To activate this mode,
click the “Calibrate” button and select a monitor group on the control sur-
face monitoring section. The offset range is from –20 dB to +10 dB. The
current calibration offset will be displayed in the display box. The calibra-
tion offset can be changed in steps of ¼ dB.
Trim Mode: Trim mode allows setting an offset for a single loudspeaker relative to
others in a group. The offset range is ±10 dB. Trim mode is selected by
clicking the “Trim” button. Select the monitor group (MAIN, ALT or
NEARFIELD) and SOLO the speaker to be offset on the on the control sur-
face monitoring section. The current Trim value of the selected speaker
will be displayed in the window. The Trim offset can be changed in steps
of ¼ dB. To clear all Trim offsets within the selected monitor group, click
the “TrimReset” button.
