D950/Vista Digital Mixing System
7-38 ConfigTool SW V3.3 Date printed: 05.08.03
To remove MADI input interfaces from the system configuration, simply
select the interface to be removed (or to remove all, select the uppermost
line) and click on the Remove button, or use the “Del” (delete) key.
Edit D21m Interfaces To add D21m input interfaces to the system configuration, simply click on
the “Add” button in the D21m Inputs area and a dialog box will appear:
The number of channels per each D21m interface has to be entered, and
the process must be repeated for every D21m interface. The number of
channels must be a multiple of eight which is the smallest function unit.
I For Specialists Only! The “start board” entry allows to set the board where the first interface
will be placed by the system (normally starts with board 00).
To add D21m output interfaces to the system configuration, simply click
on the “Add” button in the D21m Outputs area and a similar dialog box
will appear, allowing to set the number of D21m outputs.
The total number of D21m inputs does not have to be the same as the
number of outputs, since a new D21m board is added per each new inter-
face. It is prudent to keep the numbers as low as necessary in order to save
DSP power.
When operating with 96 kHz sampling frequency, the board cannot handle
96 inputs and 96 outputs. Please refer to the following table for possible
combinations of inputs and outputs.
Inputs Outputs
0 80
24 72
48 64
72 56
96 48
After adding the required interfacing, the display will show the total num-
ber of interfaces and their distribution on the D21m board(s), starting with
board number 00.
To remove D21m input interfaces from the system configuration, simply
select the interface to be removed (or to remove all, select the uppermost
line) and click on the Remove button, or use the “Del” (delete) key.
Enter the number of
D21m input interfaces
