D950 Digital Mixing System
Date printed: 03.09.03 SW V3.3 Getting started 2-35
IPL INP, IPL EQ
IPL INS, IPL KEY
IPL DYN
These five keys activate the In-Process Listening (IPL) function, if config-
ured. IPL allows monitoring of a signal after the input section, after the
EQ, after the Insert return, after Dynamics, as well as the key signal of the
Dynamic Side-chain. This mode is activated by pressing the desired IPL
key followed by the CH SEL for the desired channel. While IPL mode is
engaged it is possible to select other IPL options without further pressing
of CH SEL keys. It is also possible to select other channels while a par-
ticular IPL mode is active. To deactivate the IPL mode, press the illumi-
nated IPL key, and the console will resume normal monitoring operation.
BANK
INS
IPL
DYN
IPL
KEY
IPL
EQ
INP
IPL
IPL
STRIP
LOCK
SWAP
CHAN
RIGHT
BANKS
SPLIT
BANK
ACTIVE
ALL
SWAP
L1/L2
STO
USER
RCL
USER
ALL
L2
L1
BANK
3
BANK
4
BANK
5
1
BANK
BANK
2
