Toptech Systems MultiLoad II

Chapter 6 – Additive Control
229
Firmware Version 3/4.31.37
13. At the Remote Additive Calibration menu, select the Check Delivered option. The Check Delivered Additive
screen displays:
14. The volume measured by each injector will be displayed. Select one of the additives that were tested. The
detail screen for the selected additive displays.
PRE #1 ADTV #1 (Adtv 001 ) CALIBRATE
Delivered Vol: 0.100( 379cc)
[1]Beaker Vol: 0.000000
[2]Beaker Vol CCs: 0.000
Meter Pulses: 261
Additive Mtr K-Factr: 2600
Exit
CHECK DELIVERED ADDITIVE
P#1 A#1 Adtv 001 0.100( 379cc)
P#1 A#2 Adtv 002 (None Delivered)
Next Prev Exit Enter
