Toptech Systems MultiLoad II User Manual

Chapter 9 – Weights & Measures
311
Firmware Version 3/4.31.37
Premium/Ethanol meter (Meter Level) values are reported as:
Gpem=M1
Tpem=T1
Dpem=D1 OR ((Dp * (Gpem - Ge)) + (De * Ge)) / Gpem
Npem=Gpem*VCFp(Tpem,Dpem)
Mpem=Npem * Dpem OR Mpem=Gpem * D1
Where: Gpem=Gross volume loaded for the Premium/Ethanol Meter
M1=Gross volume reported by meter M1 while flowing Premium/Ethanol
Tpem=Temperature for the Premium/Ethanol Meter
T1= Volume weighted average temperature reported by probe T1 while flowing Premium/Ethanol
Dpem=Density for the Premium/Ethanol Meter
D1=Volume weighted average Density measured while flowing Premium/Ethanol
OR specified for meter M1
((Dp * (Gpem - Ge)) + (De * Ge)) / Gpem=Volume weighted average density for Premium/Ethanol
(see Preset Level Parameter Compute Blend Density)
Dp=Density specified for the Premium component
De=Density specified for the Ethanol component
Npem=Net volume loaded for the Premium/Ethanol Meter
VCFp=API Correction Table for Regular
Mpem=Mass loaded for the Premium/Ethanol Meter
Blended product (Preset Level) values reported as:
Gb=Grem + Gpem (value not to be used for trade)
Tb=((Trem*Grem) + (Tpem*Gpem)) / Gb (value not to be used for trade)
Db=((Drem*Grem) + (Dpem*Gpem) / Gb (value not to be used for trade)
Nb=Nrem + Npem
Mb=Mrem + Mpem
Where: Gb=Gross volume loaded for the blend
Tb=Temperature for the blend
((Trem*Grem) + (Tpem*Gpem)) / Gb =Volume weighted temperature for the blend
Db=Density for the blend
((Drem*Grem) + (Dpem*Gpem) / Gb =Volume weighted density for the blend
Nb=Net volume loaded for the blend
Mb=Mass loaded for the blend
Ethanol meter (Meter Level) values are reported as:
Gem=M2 (value not to be used for trade)
Tem=T2 (value not to be used for trade)
Dem=D2 OR De
Nem=Gem*VCFe(Tem,Dem) (value not to be used for trade)
Mem=Nem * Dem OR Mem=Gem * D1 (value not to be used for trade)
Where: Gem=Gross volume loaded for the Ethanol Meter
M2=Gross volume reported by meter M2
Tem=Temperature for the Ethanol Meter
T2= Volume weighted average temperature reported by probe T2
Dem=Density for the Ethanol Meter
