Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
380
Firmware Version 3/4.31.37
11. The MF field shows the current meter factor for the flow rate that is posted to the left of the field. This should
not be changed by the user at this point, unless a new flow rate is going to be used, as described in the
previous step.
12. Pressing the Next button will advance the user to the remaining rates and meter factors. To return to any of
the previous fields, press the Prev key.
On MultiLoad II On MultiLoad II SMP
13. When the meter proving pre-configuration is complete, press Exit to advance to the Preset Control Screen.
14. Press Enter to commence the proving run. When the Enter key is pressed, the Preset Status Screen will
appear.
15. When the preset quantity has been delivered, press Next to advance to Meter Proving Results screen
Low Sulfur Diesel
STOPPED
PRESET:
1000
DELIVER:
0
GALLONS
ExitLoad Clear=Preset Enter=Start
PRE PRODUCT SET DEL STATUS
>1 LS Diesel 1000 0 STOPPED
2 Preset 002 0 0 IDLE
Next Prev ExitLoad Enter=Pick
PRESET 01 STATUS SCREEN
PRODUCT: Low Sulfur Diesel
STATUS: LOW FLOW
GROSS NET
PRESET: 1000
REMAIN: 996
DELIVER: 3.90 3.90
TOTAL: 4
TEMPERATURE: 24.00C
PRESSURE: 0.00
DENSITY: 0.0
BSW: 0.00
FLOW RATE: 59
Next Prev Exit Stop
