Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
397
Firmware Version 3/4.31.37
Parameter
Description
Component State
Indicates the current flow state of the component. Each state will be
represented as a numerical value (see below).
State
Numeric Value
Idle
0
Low Flow
1
High Flow
2
1
st
Trip
3
2
nd
Trip
4
Final Trip
5
Gross Delivered
The gross volume that has been delivered, of the specified component, for
the current batch. Value is in whole units.
Net Delivered
The net volume that has been delivered of the specified component for the
current batch. Value is in whole units.
Mass Delivered
The amount that has been delivered, in mass, of the specified component
for the current batch. The value is in whole units.
Gross Flow Rate
The current gross flow rate, of the specified component, for the current
batch. The value is in whole units.
Temperature
The current temperature reading of the specified component. The value is in
hundredths, with an inferred decimal.
Pressure
The current pressure reading of the specified component. The value is in
hundredths, with an inferred decimal.
Density
The current density reading of the specified component. The value is in
tenths, with an inferred decimal.
Relative Density
The current relative density reading of the specified component. The value
is in ten thousandths, with an inferred decimal.
API Gravity
The current API gravity reading of the specified component. The value is in
tenths, with an inferred decimal.
VCF
The current VCF for a particular component.
CTL
The current CTL for a particular component.
CPL
The current CPL for a particular component.
Fallback Ceiling
This rate will be available when the fallback gets triggered.
