Introduction & Instrument Setup
Humphrey Field Analyzer II-
i
series User Manual 2660021145640 A
1-26
CAUTION: Carl Zeiss Meditec has tested and verified the operation of the parallel port
supported printers. It is the HFA II-i owner’s responsibility to ensure that any
unsupported printer that is used with the HFA II-i in their medical environment
satisfies the appropriate medical directives and International Safety Standards.
Note: Carl Zeiss Meditec periodically creates and releases upgrades of the system software used on
its instruments, including the HFA II-
i
perimeters. It is not possible to verify the operation of these
upgrades with all makes and models of currently available commercial printers. As a result, the
operability of unsupported printers may be affected adversely by such future software upgrades
.
Printrex: Table-Mounted and Stand-Alone Model
Use the following steps to set up your Printrex printer.
1. With power off to the table and HFA II-
i
, connect the printer interface cable to the Printrex
printer and to the Printer port on the HFA II-
i
. Attach the power cord to the special outlet
below the table for the table mounted Printrex printer. Refer to Figure 1.8, Figure 1.9, and
Figure 1.10.
2. Insert the roll of printer paper that is
provided. Refer to “Loading Paper,” on page 15-9.
3. Turn on power to the table. Turn on power to the Printrex printer.
4. Turn on power to the HFA II-
i
.
5. From the System Setup screen, select PRINTREX
from the PRINTER drop-down box. See
“Setting Up Printing,” on page 2-22 for more information.
Hewlett-Packard LaserJet
Before you start, check that you have the following supplies:
• HP LaserJet printer • HP prin
ter manual • Printer paper
• Interface cable • Toner cartridge
1. With power off to the HFA II-
i
, connect the interface cable to the Printer port on the HFA II-
i
(refer to Figure 1.8 and Figure 1.9) and the printer (refer to Hewlett-Packard printer manual).
2. Install the toner cartridge.
3. Insert paper supply.
4. Connect the printer power cord to the wall outlet.
5. Turn on power to the printer and the HFA II-
i
.
6. From the System Setup screen, select HP LASERJET fr
om the PRINTER drop-down box. See
“Setting Up Printing,” on page 2-22 for more information.
External Keyboard
The HFA II Model 750
i
comes standard with an external keyboard and glidepad combination. This
factory keyboard/glidepad is also available as an option for any of the other models of HFA II-
i
perimeters. The keyboard easily plugs into the back of the HFA II-
i
(refer to Figure 1.8 and Figure 1.9
for the location of the connector) with the use of the included PS/2 splitter
adapter. Use these steps
to connect the keyboard:
1. Power off the HFA II-
i
(keyboard will not work if connected with power already on).
2. Plug in the beige PS/2 connector on the PS/2 splitter adapter into the HFA Keyboard/Mouse port.
