Networking

Humphrey Field Analyzer II-

series User Manual 2660021145640 A

14-22

Manually Retrieving Archived Data

You can perform the archive retrievals manually by using the procedur

es that follow, even if your

Network Administrator has set up automatic archive retrieval.

Note: The retrieve process will not work until you have first ar

chived data to the server. If you have

several HFA II-

perimeters in your network, each one must have been archived previously, before

you can retrieve data from all of them.

Performing an Archive Retrieval Manually

1 Select

FILE FUNCTIONS

>ARCHIVE/RETRIEVE.

2 You will see a dialog like that shown in Figure 14.22. Select RETRIEVE.

Figure 14.22 Archive/Retrieve Selection Dialog

3 A browser window (Figure 14.23) will open to allow you to select the HFAs you wish to retrieve

data from. The archives are named with the model number and serial number of the HF

A II-

from which the data was archived (

e.g.,

750i-123456). Select the individual HFA II-

archives by

pressing each entry to add a check mark to the left of it. If you make a selection error, press the

entry a second time to de-select it.

Figure 14.23 Database Retrieval Screen

Note: You can select as many HFA II-

instruments as you wish, by selecting their individual serial

numbers to place a check mark to the left of each serial number entry.

4 Ensure that you have checkmarked each HFA II-

for which you wish to retrieve previously

archived data. You can only manually synchronize the complete series of HFA II-

perimeters if

you have selected all of them in the browser screen.
