Diagnostic Codes 9980 Self-Propelled Peanut Combine
Control Unit SPN FMI Priority
Description
ECU 110 15 Warning
Engine coolant temperature too high -least severe level.
Maximum power level is derated. Power boost is disabled.
ECU 110 16 Warning
Engine coolant temperature too high -moderately severe
level. Maximum power level is derated. Power boost is disabled.
ECU 110 17 Warning
Engine coolant temperature too low -least severe level.
ECU 157 01 Stop
Fuel pressure low -most severe level. (6135)
ECU 157 03 Stop
Rail pressure sensor (cc# 5475) voltage out of range high.
(6068, 6090)
ECU 157 03 Warning
Rail pressure sensor (cc# 5469) voltage out of range high. (6135)
ECU 157 04 Stop
Rail pressure sensor (cc# 5475) voltage out of range low.
(6068, 6090)
ECU 157 04 Warning
Fuel pressure sensor (cc# 5469) voltage out of range low. (6135)
ECU 157 10 Warning
Rail pressure (cc# 5475) drops too fast when engine is motoring
and high pressure pump is off. (6068, 6090)
ECU 157 16 Warning
Fuel pressure high -moderately severe level. (6135)
ECU 157 17 Warning
Rail pressure (cc# 5475) is below 10 mPa during starting.
(6068, 6090)
ECU 157 18 Warning
Fuel pressure low -moderately severe level. (6135)
ECU 158 17 Warning
Controller not powered down properly. Battery voltage does
not go to 0 VDC.
ECU 174 00 Warning
Engine fuel temperature high -most severe level.
ECU 174 03 Warning
Engine fuel temperature sensor voltage is out of range high.
ECU 174 04 Warning
Engine fuel temperature sensor voltage is out of range low.
ECU 174 16 Warning
Engine fuel temperature too high -moderately severe level.
ECU 189 00 Stop
Engine speed derated.
ECU 412 00 Stop
Exhaust temperature high -most severe level.
ECU 412 03 Warning
Exhaust temperature out of range high.
ECU 412 04 Warning
Exhaust temperature out of range low.
ECU 412 15 Warning
Exhaust temperature high -least severe level.
ECU 412 16 Stop
Exhaust temperature high -moderately severe level.
ECU 611 03 Stop
The injector driver has detected a short to voltage in the
injector wiring.
ECU 611 04 Stop
The injector driver has detected a short to ground in the
injector wiring.
ECU 627 01 Warning
Injector pull-in current too low or hold current incorrect.
ECU 627 18 Warning
Low voltage.
ECU 629 13 Stop
Control unit ECU has not been programmed.
ECU 636 02 Warning
Electrical noise is detected on the engine position signal
(cc# 5445).
ECU 636 05 Warning
Engine position signal (cc# 5445) current too low.
ECU 636 06 Warning
Engine position signal (cc# 5445) current too high.
ECU 636 08 Warning
Engine position signal (cc# 5445) signal is missing.
ECU 636 10 Warning
Engine position signal (cc# 5445) signal has incorrect pulse
pattern.
370 09/08/15 MAN141
