AFE INTERRUPTS
analog.com Rev. A | 140 of 312
Table 178. Bit Descriptions for INTCFLAG0 and INTCFLAG1 Registers
Bits Bit Name Settings Description Reset Access
31 FLAG31 Attempt to Break IRQ Status. This bit is set if a Sequence B request arrives when Sequence A is
running, indicating that Sequence B is ignored.
0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
30 Reserved Reserved. 0x0 R
29 FLAG29 Outlier IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
28 Reserved Reserved. 0x0 R
27 FLAG27 Data FIFO Underflow IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
26 FLAG26 Data FIFO Overflow IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
25 FLAG25 Data FIFO Threshold IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
24 FLAG24 Data FIFO Empty IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
23 FLAG23 Data FIFO Full IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
[22:18] Reserved Reserved. 0x0 R
17 FLAG17 Sequencer Timeout Error IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
16 FLAG16 Sequencer Timeout Finished IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
15 FLAG15 End of Sequence IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
14 Reserved Reserved. 0x0 R
13 FLAG13 Bootload Done IRQ Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
12 FLAG12 Custom Interrupt 3 Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
11 FLAG11 Custom Interrupt 2 Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
10 FLAG10 Custom Interrupt 1 Status. 0x0 R
0 Interrupt not asserted.
1 Interrupt asserted.
9 FLAG9 Custom Interrupt 0 Status. 0x0 R
