Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Power Plant
E4.08.04
Rev. 29
Page 275
71 -Maintenance Procedures
01-Jul-2020
Repair a sensor cable branch
This section contains general instructions to repair a defective connector / cable branch with a
repair kit.
The following description is a standard. The figures are only an example of the basic procedure.
Refer to Table 71 - 2 for the cable branches applicable repair kits.
Connector /
Cable Branch
Repair Kit
Comment
1
CAS1
E4A-95-R15-000
2
CAS2
E4A-95-R15-000
3
CTS
E4A-95-R12-000
4
FTS
E4A-95-R12-000
5
CTS_GPC
E4A-95-R12-000
Shielding not required
6
GBTS
E4A-95-R12-000
7
MOK
E4A-95-R16-000
8
IAT1
E4A-95-R13-000
Shared ring terminal with BPS1
9
IAT2
E4A-95-R13-000
Shared ring terminal with BPS2
10
BPS1
E4A-95-R16-000
Shared ring terminal with IAT1
11
BPS2
E4A-95-R16-000
Shared ring terminal with IAT2
12
OPS
E4A-95-R14-000
13
FPS
E4A-95-R14-000
Perform RSB-E4-021 on FPS connector
14
CRS1
E4A-95-R19-000
15
CRS2
E4A-95-R19-000
16
BPA
E4A-95-R20-000
17
INJ1
E4A-95-R21-000
Shielding not required
18
INJ2
E4A-95-R21-000
Shielding not required
19
INJ3
E4A-95-R21-000
Shielding not required
20
INJ4
E4A-95-R21-000
Shielding not required
Table 71 - 2 Sensor branch repair kits
