6-72
Configuring the Data Link Layer Protocol for E1, T1, and Serial Interfaces
Quick Start
2. Set a static IP address.
Syntax: ip address <A.B.C.D> <subnet mask | /prefix length>
For example, you might enter:
ProCurve(config-ppp 1)# ip address 10.1.1.1 /24
3. Activate the PPP interface
ProCurve(config-ppp 1)# no shutdown
4. Bind the physical interface to the logical interface.
Syntax: bind <number> <physical interface> <slot>/<port> [<tdm-group
number>] <logical interface> <logical interface number>
For example, to bind the T1 interface to the PPP interface, enter:
ProCurve(config-ppp 1)# bind 1 t1 1/1 1 ppp 1
To bind the serial interface to the PPP interface, enter:
ProCurve(config-ppp 1)# bind 1 ser 1/1 ppp 1
Note If you are binding a serial interface to the PPP interface, you do not include
the TDM group number because you do not use TDM groups on a serial
interface.
5. View the status of the PPP interface.
ProCurve(config-ppp 1)# do show interface ppp 1
PPP Authentication
If you are configuring PPP authentication, you may want to print Table 6-16
and enter the information for your router.
Table 6-16. Quick Start Worksheet
Parameter Your Setting
PPP interface number
authentication protocol
Are you requiring the peer to
authenticate itself?
Yes/No
peer username
peer password
