14-59
Using the Web Browser Interface for Basic Configuration Tasks
Configuring a Serial Interface for an E1- or T1-Carrier Line
Configuring a Serial Interface for an
E1- or T1-Carrier Line
If your public carrier provided you with an external CSU/DSU, you purchased
a serial module for the ProCurve Secure Router. When you set up an E1- or
T1-carrier line, you must configure the Physical Layer and the Data Link Layer.
This section explains how to configure the Physical Layer—the serial inter-
face. If you need additional information about any of the options, see Chapter
4: Configuring E1 and T1 Interfaces.
1. In the navigation bar of the Web browser interface, select Physical
Interfaces. The interfaces for all of the modules installed in the router are
listed on the Physical Interfaces window.
2. Select the serial interface that you want to configure. The Configuration
for Serial <port number>/<slot number> window is displayed.
Figure 14-42. Configuration for Serial Window
