ADSL WAN Connections
Viewing the Status and Configuration of Interfaces
Figure 7-18. show running-config interface adsl verbose Command
Viewing the Status of the ATM Interface and Subinterface
To view the status of the ATM interface, enter the following command from
the enable mode context:
Syntax: show interfaces atm <number>
Replace <number> with the unique number that you assigned the ATM
interface. For the ATM 1 interface, enter:
ProCurve# show interfaces atm 1
Figure 7-19 shows the output from this command for a sample network. As
you can see, this command displays the status of the interface and the number
of virtual circuits active on the interface.
Figure 7-19. show interfaces atm Command
To view the status of the ATM subinterface, enter the following command from
the enable mode context:
Syntax: show interfaces atm <number.subinterface number>
interface adsl 2/1
description ""
alias ""
snr-margin 5
training-mode Multi-Mode
no shutdown
Displays all the settings for the
interface, including defaults
atm 1 is UP, line protocol is UP
BW 896 Kbit/s
16 maximum active VCCs, 16 VCCs per VP, 1 current VCCs
Queueing strategy: Per VC Queueing
5 minute input rate 58120 bits/sec, 0 packets/sec
5 minute output rate 58200 bits/sec, 0 packets/sec
10007 packets input, 2520900 bytes
0 pkts discarded, 0 error pkts, 0 unknown protocol pkts
60024 cells received, 0 OAM cells received
10062 packets output, 2524900 bytes
0 tx pkts discarded, 0 tx error pkts
60123 cells sent, 0 OAM cells sent
Interface is up
Number
of virtual
circuits
