8-75
Configuring Demand Routing for Primary ISDN Modules
Troubleshooting Demand Routing
Figure 8-26. Viewing ISDN debug Messages
Test Calls
You can also set up a test call to test the ISDN circuit. When you initiate a test
call, you connect the two endpoints through an ISDN call without setting up
a Data Link Layer connection; test calls only connect at the Physical Layer.
When you initiate a test call, the ProCurve Secure Router assigns the BRI
interface to ISDN group 0 for the duration of the call.
2005.10.08 11:23:09 L2_MSG BRI 2/1 Recd = 02 FF 03 08 01 01 05 A1 04 02 88 90 18 01 89 6C
2005.10.08 11:23:09 L2_MSG BRI 2/1 0C 21 80 30 30 30 39 36 33 31 31 31 31 70 08 C1
2005.10.08 11:23:09 L2_MSG BRI 2/1 39 36 33 33 33 33 33
2005.10.08 11:23:09 L2_FMT BRI 2/1 =============================================
2005.10.08 11:23:09 L2_FMT BRI 2/1 Recd = Sapi:00 C/R:C Tei:7F
2005.10.08 11:23:09 L2_FMT BRI 2/1 Ctl:UI
2005.10.08 11:23:09 L2_FMT BRI 2/1 Prot:08 CRL:1 CRV:0001
2005.10.08 11:23:09 L2_FMT BRI 2/1 M - 05 SETUP
2005.10.08 11:23:09 L2_FMT BRI 2/1 IE - A1 SENDING COMPLETE Len=0
2005.10.08 11:23:09 L2_FMT BRI 2/1 IE - 04 BEARER CAPABILITY Len=2
2005.10.08 11:23:09 L2_FMT BRI 2/1 88 Xfer Cap.:UNRESTRICTED DIG.
2005.10.08 11:23:09 L2_FMT BRI 2/1 90 Xfer Rate:64k
2005.10.08 11:23:09 L2_FMT BRI 2/1 IE - 18 CHANNEL ID Len=1
2005.10.08 11:23:09 L2_FMT BRI 2/1 89 Basic Rate
2005.10.08 11:23:09 L2_FMT BRI 2/1 Intfc ID:IMPLICIT
2005.10.08 11:23:09 L2_FMT BRI 2/1 Pref/Excl:EXCLUSIVE
2005.10.08 11:23:09 L2_FMT BRI 2/1 D-Chan Indicated:NO
2005.10.08 11:23:09 L2_FMT BRI 2/1 Chan. Sel:B1
2005.10.08 11:23:09 L2_FMT BRI 2/1 IE - 6C CALLING PARTY # Len=12
2005.10.08 11:23:09 L2_FMT BRI 2/1 21 Numb. Type:NATIONAL
2005.10.08 11:23:09 L2_FMT BRI 2/1 Numb. Plan:ISDN/Telephony
2005.10.08 11:23:09 L2_FMT BRI 2/1 80 Presentation:ALLOWED
2005.10.08 11:23:09 L2_FMT BRI 2/1 Ph.# 0009631111
2005.10.08 11:23:09 L2_FMT BRI 2/1 IE - 70 CALLED PARTY # Len=8
2005.10.08 11:23:09 L2_FMT BRI 2/1 C1 Numb. Type:SUBSCRIBER
2005.10.08 11:23:09 L2_FMT BRI 2/1 Numb. Plan:ISDN/Telephony
2005.10.08 11:23:09 L2_FMT BRI 2/1 Ph.# 9633333
2005.10.08 11:23:09 CC_MSG BRI 2/1 CC>>Host: 01 000b SETUP_IND
2005.10.08 11:23:09 CC_IE BRI 2/1 ie: 00 04 04 80 88 80 90
2005.10.08 11:23:09 CC_IE BRI 2/1 ie: 00 18 04 80 81 80 81
2005.10.08 11:23:09 CC_IE BRI 2/1 ie: 00 6C 0E 82 81 80 80 30 30 30 39 36 33 31 31 31 31
2005.10.08 11:23:09 CC_IE BRI 2/1 ie: 00 70 09 84 81 39 36 33 33 33 33 33
2005.10.08 11:23:09 EP BRI 2/1 Incoming call :'9633333' from '0009631111'.
2005.10.08 11:23:09 CC_MSG BRI 2/1 Host>>CC: 01 000b CALL_PROCEEDING_REQ
2005.10.08 11:23:09 EP BRI 2/1 Incoming call to '9633333' accepted
2005.10.08 11:23:09 L2_MSG BRI 2/1 Sent = FC FF 03 0F 11 25 01 FF
