Configuring the E1 + G.703 and T1 + DSX-1 Modules
Configuring the T1 + DSX-1 Module
Activating the DSX-1 Interface
By default, all interfaces on the ProCurve Secure Router are administratively
down. To activate the interface, enter:
ProCurve(config-t1 1/2)# no shutdown
Checking the Status of the DSX-1 Interface
To check the status of the DSX-1 interface, enter the following command from
the enable mode context:
Syntax: show interfaces t1 <slot>/2
Figure 9-5 shows the output for a sample DSX-1 interface.
Figure 9-5. show interface t1 Command for the DSX-1 Port
The first line in the output tells you whether the interface is up or down. The
first block of text indicates the current configurations for the interface,
including line length and signaling mode, as well as line coding and framing.
The second block of text, headed “Current Performance Statistics,” displays
errors. Steadily incrementing errors indicate that you need to resolve prob-
lems with the configuration.
t1 2/2 is UP
Receiver has no alarms
T1 coding is B8ZS, framing is ESF
Line length is 55 feet
Signaling mode: robbed bit
No remote loopbacks, No network loopbacks
Tx Alarm Enable: rai
Last clearing of counters never
loss of frame : 0
loss of signal : 0
AIS alarm : 0
Remote alarm : 0
Line Status: -- No Alarms --
Current Performance Statistics:
5 Errored Seconds, 0 Bursty Errored Seconds
5 Severely Errored Seconds, 5 Severely Errored Frame Seconds
0 Unavailable Seconds, 0 Path Code Violations
1 Line Code Violations, 0 Controlled Slip Seconds
0 Line Errored Seconds, 0 Degraded Minutes
No channel assignments are displayed
here for the DSX-1 interface
To view channel assignments for this
interface, enter:
show interface t1 <slot>/1
