HP ProCurve 7000dl Series User Manual

6-25
Configuring the Data Link Layer Protocol for E1, T1, and Serial Interfaces
Configuring the Logical Interface
The Frame Relay settings are described in the sections that follow.
Activate the Frame Relay Interface
You must activate the Frame Relay interface. From the Frame Relay interface
configuration mode context, enter:
ProCurve(config-fr 1)# no shutdown
Define the Signaling Role
You must configure the signaling role that the ProCurve Secure Router will
fulfill in the Frame Relay network. With few exceptions, the ProCurve Secure
Router will function as the user, or DTE, and consequently, this is the default
setting.
However, the other options are available if you should ever need to change
the signaling role. For example, if you are setting up a test WAN to determine
if your applications will run over a Frame Relay connection, you may need to
configure the router as a DCE.
frame-relay
subinterface
• frame-relay interface-dlci <dlci>
• ip address <A.B.C.D> <subnet mask | /prefix
length>
or
• ip address dhcp {client-id [ethernet 0/
<port> | HH:HH:HH:HH:HH:HH:HH] |
hostname <word>}
• ip address dhcp [hostname <word> | no-
default-route | no-domain-name | no-
nameservers]
or
• ip unnumbered <interface>
• defines the DLCI for the PVC
• defines a static IP address for the
interface
• configures the Frame Relay
subinterface as a DHCP client
• configures the Frame Relay as an
unnumbered interface, which takes
its IP address from another
interface
6-28
global
configuration or
interface
configuration
• bind <number> <physical interface> <slot>/
<port> [<tdm-group number>] Frame Relay
<interface number>
• binds the physical interface to the
logical interface
• requires tdm-group number for E1
and T1 interfaces (but not for serial
interfaces)
6-36
Interface
Configuration
Mode Context
Command Description Page
