6-77
Configuring the Data Link Layer Protocol for E1, T1, and Serial Interfaces
Quick Start
4. Bind the physical interface—the E1, T1, or serial interface—to the logical
interface.
Syntax: bind <number> <physical interface> <slot>/<port> [<tdm-group
number>] <logical interface> <logical interface number>
For example, to bind the E1 1/1 interface to the HDLC 1 interface, enter:
ProCurve(config-hdlc 1)# bind 1 e1 1/1 1 hdlc 1
To bind the serial 1/1 interface to the HDLC 1 interface, enter:
ProCurve(config-hdlc 1)# bind 1 ser 1/1 hdlc 1
Note If you are binding a serial interface to the HDLC interface, you do not include
the TDM group number because you do not use TDM groups on a serial
interface.
5. View the status of the HDLC interface. From the enable mode context,
enter:
ProCurve# show interface hdlc 1
