HP ProCurve 7000dl Series User Manual

1-21
Overview
Hardware Overview
Figure 1-13. E1/T1 Toggle Switch
Note Although the ProCurve Secure Router 7203dl can support up to 12 E1 or T1
lines, the router supports full throughput for up to 8 E1 or T1 lines.
You can configure each of the eight ports independently with separate clock
sources, frame formats, and other specifications.
Figure 1-14. The Eight-port T1/E1 Module
E1/T1 Toggle
Switch
Port Numbers
