4.36 Valve gates - Tab1
4.36.1 Purpose
This mask is used to adjust the settings for available valve gates.
Information
This mask is only visible if a valve gate is available and configured.
4.36.2 Description of the mask
The single valve gates can be activated and deactivated in this mask. Fur-
thermore settings for opening and closing of a valve gate can be done.
Fig.4-39: Mask "Valve gates tab1"
4.36.3 Description of the elements
Information
During inject process (including hold) at least one valve gate must be open.
Otherwise an alarm appears and the inject process will be stopped.
Below the valve gate number an icon shows if the corresponding valve gate is
actually actuated.
