Designation Description
Production time
The Actual production time is shown in the left
field Actual. The remaining production time is
shown in the center field Remain. The total
production time is shown in the right field To-
tal.
Oil Actual oil temperature.
Cycle time
The current cycle time and last cycle time is
displayed. In the right field the maximum al-
lowed cycle time can be adjusted, which also
can be done in mask "Production".
Mold data
Displays active mold data record.
4.3 Mold - Tab Profile
4.3.1 Purpose
The settings for the mold that is currently in operation can be adjusted in this
mask.
4.3.2 Description of the mask
Pressure and velocity can be defined for specific sections of the mold's move-
ment. The values for mold "Open" and "Close" are specified separately.
Fig.4-5: Mask "Mold profile"
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.0544
