Fig.4-3: Mask "Overview vertical"
4.2.3 Description of the elements
Heating zones
Up to 7 heating zones plus a hopper temperature status can be displayed here.
The current temperature is shown in the middle of the respective heating
zones. Error states of the heating zones are shown in the status bar along the
upper border of the image.
Information
The display depends on the number of heating zones.
Fig.4-4: Depiction of the heating zones
1
... Status of the heater (zone is heating / not
heating, error of a heating zone )
2 ... Status of the heater (grey....temper-
ature out of tolerance, green...target
temperature attained)
3 ... %....displays a setter zone 4 ... Actual temperature
5 ... Displays a hopper zone for material en-
trance
Description of the operating masks KePlast.HMI.KVB
© KEBA 2016
User's manual V3.0542
