Delay times
Field Description
Inject delay
Field Pump on specifies the time that is waited between the start
of the inject movement and the activation of the hydraulic pump.
Field Valve off determines the time that is waited between the end
of the inject movement and the closing of the control valve in order
to release the remaining pressure.
Ramp setup mode
Field Description
Ramp setup mode inject
Ramp (pressure and velocity) in setup mode for inject movement
is adjusted here.
4.32 Inject Setup Advanced - Tab2
4.32.1 Purpose
Additional parameters for plasticize and decompression can be configured
within this mask.
4.32.2 Description of the mask
For plasticize and decompression the minimum profile outputs, maximum ramp
settings and pump and valve delay times can be set.
Fig.4-35: Mask "Inject setup advanced tab2"
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.0596
