4.44 Heating Nozzle
4.44.1 Purpose
This mask is used to adjust the settings for nozzle heater.
4.44.2 Description of the mask
The individual heating zones are graphically depicted in the section Heating
zones. The current temperature is shown in the middle of each heating zone.
The input fields for the set-point temperature and tolerance are located under-
neath the heating zones.
Information
The display depends on the number of heating zones.
General settings for the nozzle heater and the material entrance are configured
in the lower section of the mask.
Fig.4-48: Mask "Heating Nozzle"
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 117
