Information
Long pressing of Zoom In- buttons automatically scales the diagram to full
screen- size.
Long pressing of Zoom Out- buttons automatically scales the diagram to
100%.
Navigation inside the mask is possible by using the cursor buttons of the op-
erating panel.
Fig.4-61: Mask "Energy Chart (by shot)"
4.57.3 Description of the elements
Field Description
Zoom X Out Zoom out in x- direction.
Zoom X In Zoom in in x- direction.
Zoom Y Out Zoom out in y- direction.
Zoom Y In Zoom in in y- direction.
Hold / Run
Stops and starts the graphic recording.
A vertical red cursor is displayed which is used
for navigation inside the diagram by pressing
left and right cursor buttons of the operating
panel. Thus it is possible to navigate to each
single shot and read out the actual value.
Keys
Fades- in and fades- out the legend. The leg-
end shows the actual energy consumption of
the machine.
Description of the operating masks KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05138
