4.3.3 Description of the elements
Mold close
Field Description
Stages Number of adjustable stages (maximum of 5).
Close 1..n
Setting of Pressure and Velocity between the
position specified in field to and the position of
the the previous stage during "Mold close" (in
case of stage 1, the "Mold open" position).
Protect
Setting of Pressure and Velocity between the
position specified in field to and the position of
the the previous stage during "Mold close".
Mold protect is active in this range.
High Pressure
Setting the Pressure and Velocity if the mold
is closed.
Fast close
Activates an additional valve in order to feed
the return oil for the mold closing movement.
This option is only available for hydraulic ma-
chines if an additional valve for fast close has
been configured.
Clamp force
The left field displays the current clamp force.
The set value for clamp force is specified in the
right field.
This field is only shown if a clamp force sensor
is available.
Cycle delay time
Defines a delay time between production cy-
cles in automatic mode.
Mold protect time
Setting of the maximum period between the
specified mold protect position and the position
of the previous stage.
If this period is exceeded an alarm is triggered.
Protect from-to
Mold protect is active in the range specified
here. Position range from the previous stage to
mold protect stage.
Mold open
Field Description
Stages Number of adjustable stages (maximum of 5).
Open 1..n
Setting of Pressure and Velocity between the
position specified in field to and the position of
the the previous stage during "Mold open" (in
case of stage 1, the "Mold close" position).
Pressure release endposition
High pressure release valve is closed if this
mold position is reached during mold open
movement.
This field is only shown for direct clamping ma-
chines and if a high pressure release valve is
available.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 45
