Core delay times
Field Description
Core in delay
Field Pump on specifies the time that is waited between the start
of the core in movement and the activation of the hydraulic pump.
Field Valve off determines the time that is waited between the end
of the core in movement and the closing of the control valve in
order to release the remaining pressure.
Core out delay
Field Pump on specifies the time that is waited between the start
of the core out movement and the activation of the hydraulic pump.
Field Valve off determines the time that is waited between the end
of the core out movement and the closing of the control valve in
order to release the remaining pressure.
4.24 Core Setup Advanced - Tab2
4.24.1 Purpose
Additional parameters for the core can be configured within this mask.
4.24.2 Description of the mask
For the core movement the ramp settings and pump and valve delay times can
be set.
Fig.4-27: Mask "Kern setup advanced - Tab2"
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.0584
