4.58 Energy Chart (by time)
4.58.1 Purpose
The mask energy chart (by time) is used to record and display the power con-
sumption of the machine during a complete machine cycle.
Information
The mask is only displayed if the option speed pump is used.
4.58.2 Description of the mask
The power consumption of the machine for a complete machine cycle is dis-
played graphically in [kW] and results from the motor and heating power
consumption. The [%]- value on the left y- axis shows which area of the chart
is actually displayed. On the x- axis the cycle time is displayed. Button Keys
fades- in resp. fades- out a legend which shows the actual power consumption
and its color-coded assignments. A further diagram shows at which moment
the movements "Mold open", "Mold close", "Plasticize" and "Inject" are active
during machine cylce. Thus it is possible to visualize the power consumption
during the single movements.
By using the Zoom- buttons it is possible to zoom in and out in inside the
diagram.
Information
Long pressing of Zoom In- buttons automatically scales the diagram to full
screen- size.
Long pressing of Zoom Out- buttons automatically scales the diagram to
100%.
Navigation inside the mask is possible by using the cursor buttons of the op-
erating panel.
Information
The time on the x- axis gets scaled automatically with every cycle depending
on the current cycle time.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 139
