4.14.3 Description of the elements
WARNING!
The system (hardware and software) only meets category B according to
EN ISO 13849-1. Thus it is not intended for usage in safety-relevant control ap-
plications in the field of personal safety (e.g. emergency stop).
To implement potentially necessary safety-relevants control tasks, always use
additional external safety devices according to EN ISO 13849-1 that are intended
for the particular purpose and meet the necessary functional safety.
For further information see EN ISO 13849-1 and refer to chapter "EC directives
and standards" in the manuals for a list of norms applying to the product.
The safety notices for the installation and commissioning of the product can be
found in the user manuals of the components or in the system manual and must
be read and observed before installation or commissioning.
The user manual must be kept throughout the entire service life of the product.
Automatic safety gate
Field Description
Safety gate auto open
mode
The behaviour of the automatic safety gate during autocycle can
be adjusted here. Following mode are possible:
Not open
Safety gate is not opened automatically.
After mold open
Safety gate is opened after end of mold opening sequence and
closed before begin of closing sequence.
Safety Gate auto open time
If this time is expired, the safety gate open movement stopps. Set-
ting the value to 0.0s deactivates this function.
Time settings
Field Description
Max. close time
If this time is exceeded during safety gate close, the closing move-
ment stopps and an alarm will be triggered.
Max. open time
If this time is exceeded during safety gate open, the opening
movement stopps and an alarm will be triggered.
Close delay The delay time for auto safety gate close is adjusted here.
Open delay The delay time for auto safety gate open is adjusted here.
Safety gate close
Field Description
Close fast
Pressure and velocity setting for fast close movement of safety
gate.
Close slow
Pressure and velocity setting for slow close movement of safety
gate.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 65
