Field Description
Number of cylinders The number of cylinders is specified here.
Move in by ring area
This field must be activated, if the mechanical integration of the
hydraulic cylinder for this movement requires that the movement
'Slide table fwd' is controlled by the ring area of the cylinder.
4.100
Machine limits
4.100.1 Purpose
This mask is used to set the principal limits of the machine.
4.100.2 Description of the mask
The mask is divided into the sections
● Flow
● Screw
● Pressure and clamping force
Fig.4-106: Mask "Machine limits
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05200
