4.88.3 Description of the elements
Measurement
Field Description
Configuration
The name of the currently active scope configuration. If no con-
figuration is loaded "---" is displayed.
Measurement state
The current scope state:
● Idle: The sampling is deactivated. The user is allowed to select
and load configurations and change the settings on the mask.
● Wait for start: The sampling is activated and it is waited for
the start trigger.
● Recording: The sampling is currently in progress.
● File write active: The measurement is finished (e.g. the stop
trigger occured) and the recorded data is written to a file.
● Export active: The export action is currently in progress (e.g.
the recorded sampler files are copied to the USB stick).
● Read config: A configuration is currently loaded.
Measurement time
The right parameter specifies the measurement duration. This du-
ration specifies the maximum time that is sampled. This parameter
should at least be the amount of time between the occurence of
the start- and stop trigger (plus the configured stop trigger delay)
to cover the whole measurement duration.
The left parameter shows the current measure time of the record-
ing.
The maximum time is directly proportional to the allocated meas-
urement buffer and therefore limited by the amount of system
memory available, the number of sampled variables and the sam-
pling rate. The measurements are stored in a ring buffer and stores
the latest measurements, in case the measure time is lower than
the time between the triggers.
Settings for saving measurement data
Field Description
Measure cycle count
The right parameter specifies the number of recordings that are
made before the export action is started.
The left parameter shows the number of the current measure cy-
cle.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 181
