4.98.3 Description of the elements
Mold
Field Description
Max. mold stroke
The maximum stroke of the moveable plate is adjusted here (dis-
tance between "Mold close" and "Mold open").
Cylinder diameter The diameter of the cylinder(s) is specified here.
Piston rod diameter The diameter of the piston rod(s) is specified here.
Number of cylinders The number of cylinders is specified here.
Mold close by ring area
This field must be activated, if the mechanical integration of the
hydraulic cylinder for this movement requires that the movement
'Mold close' is controlled by the ring area of the cylinder.
Ejector
Field Description
Max. ejector stroke
This setting defines the maximum stroke of the ejector (distance
between "Ejector Out" and "Ejector In").
Cylinder diameter The diameter of the cylinder(s) is specified here.
Piston rod diameter The diameter of the piston rod(s) is specified here.
Number of cylinders The number of cylinders is specified here.
Move forward by ring area
This field must be activated, if the mechanical integration of the
hydraulic cylinder for this movement requires that the movement
'Ejector forward' is controlled by the ring area of the cylinder.
Inject
Field Description
Max. screw stroke
The maximum distance between front and rear end position of the
screw is specified here.
Screw diameter The diameter of the screw is specified here.
Cylinder diameter The diameter of the cylinder(s) is specified here.
Piston rod diameter The diameter of the piston rod(s) is specified here.
Number of cylinders The number of cylinders is specified here.
Do injection by ring area
This field must be activated, if the mechanical integration of the
hydraulic cylinder for this movement requires that the injection is
controlled by the ring area of the cylinder.
Nozzle
Field Description
Max. nozzle stroke
Specification of the maximum nozzle stroke possible.
This setting is only shown if a position sensor for the nozzle is
available.
Cylinder diameter The diameter of the cylinder(s) is specified here.
Piston rod diameter The diameter of the piston rod(s) is specified here.
Description of the operating masks KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05198
