4.32.3 Description of the elements
Minimum profile output
Field Description
Min. profile output plasti-
cize
The minimum profile output (pressure, velocity) for the plasticize
movement is adjusted here. The output in any section of the profile
never falls below this value.
Min. profile output decom-
pression
The minimum profile output (pressure, velocity) for decompression
is adjusted here. The output in any section of the profile never falls
below this value.
Ramp profile output
Field Description
Max. ramp Plasticize
The maximum ramp (backpressure, pressure, velocity) for the the
plasticize movement is adjusted here.
Max. ramp decompression
before plasticize
The maximum ramp (pressure, velocity) for the the decompression
before plasticize movement is adjusted here.
Max. ramp decompression
after plasticize
The maximum ramp (pressure, velocity) for the the decompression
after plasticize movement is adjusted here.
Delay times
Field Description
Plasticize delay
Field Pump on specifies the time that is waited between the start
of the plasticize movement and the activation of the hydraulic
pump.
Field Valve off determines the time that is waited between the end
of the plasticize movement and the closing of the control valve in
order to release the remaining pressure.
Decompression delay
Field Pump on specifies the time that is waited between the start
of the decompression movement and the activation of the hy-
draulic pump.
Field Valve off determines the time that is waited between the end
of the decompression movement and the closing of the control
valve in order to release the remaining pressure.
Ramp setup mode
Field Description
Ramp setup mode plasti-
cize
Ramp (pressure and velocity) in setup mode for plasticize move-
ment is adjusted here.
Ramp setup mode decom-
pression
Ramp (pressure and velocity) in setup mode for decompression
movement is adjusted here.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 97
