4.66.3 Description of the elements
Field Description
DI 0...DI n
The descirption of the digital input is displayed.
The left grey field indicates the current state of
the digital input.
The right input field activates the force of the
digital input.
Icon filled green.
Digital input state High
Icon not filled.
Digital input state Low
Icon filled and red border.
Digital input forced.
Icon not filled and red border.
Digital input unforced.
Icon with red cross.
Digital input erroneous.
4.67 IO Monitor Digital Outputs
4.67.1 Zweck
This mask shows the values of the digital outputs of the controller.
Information
The IO Monitor masks for the digital outputs of the panel (PO) are working
the same way.
4.67.2 Description of the mask
The state of all digital outputs is displayed. Further it is possible to force a digital
output.
If an IO is physically available but no variable is allocated to the IO, only the
IO- number is displayed. However it is possible to force the IO.
If an IO is physically available and allocated to a variable but no text is assigned
to the variable, the name of the system variable is displayed.
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05152
