Field Description
Use
Activate/Deactivate a valve gate.
Each valve gate has two input fields for using/not using. Thus dur-
ing inject process (except hold process) a valve gate can be
opened and closed twice.
e.g. valve gate 1 opens at position 120mm, closes at position
80mm, opens again at position 60mm and closes again at position
30mm.
Mode
(Open at inject)
Mode of opening a valve gate with the following options.
● Pos:Setting of a time and position is possible. Position defines
at which screw position the valve gate opens. Set time value
defines a delay time which has to elapse after reaching the set
screw position before the valve gate opens.
● Time:Definition of a position is not possible. Set time value
defines a delay time which has to elapse after inject starts be-
fore the valve gate opens.
For the second time opening a valve gate, the modes are not se-
lectable. The modes of the first opening and closing are taken.
Mode
(Close at inject)
Mode of closing a valve gate with the following options.
● Pos:Setting of a time and position is possible. Position defines
at which screw position the valve gate closes. Set time value
defines a delay time which has to elapse after reaching the set
screw position before the valve gate closes.
● Time: Definition of a position is not possible. Set time value
defines a delay time which has to elapse before the valve gate
closes. The delay time starts after the valve gate is open.
For the second time closing a valve gate, the modes are not se-
lectable. The modes of the first opening and closing are taken.
Hold
Mode of opening a valve gate during hold with the following op-
tions.
● Use:Activates the option, that a valve gate opens during hold
with the defined parameters for 'Delay' and 'Time'.
● Delay: Definition of a delay time which has to elapse after
reaching cut off before the valve gate opens.
● Time: Definition how long the valve gate is open during hold.
● Force: Only selectable in setup mode. This option forces a
valve gate to open independent of the set time parameters.
4.38 Valve gates - Tab Setup
4.38.1 Purpose
This mask is used to adjust the general settings for available valve gates.
Information
This mask is only visible if a valve gate is available and configured.
Description of the operating masks
KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05106
