4.11 Lubrication
4.11.1 Purpose
The lubrication settings for the machine can be configured within this mask.
4.11.2 Description of the mask
Lubrication interval, the lubrcation duration as well as on and off time of the
lubrication can be set.
Fig.4-13: Mask "Lubrication"
4.11.3 Description of the elements
Field Description
Lubrication interval
The left field displays the number of machine cycles since its last
lubrication.
In the right field the number of machine cycles after which a lubri-
cation has to take place can be set.
Lubrication time
The left field displays the current lubrication time. In the right field
the duration of a lubrication can be set.
On time
The lubrication will be done pulsative.
The left field displays the current active time of the lubrication
pulse. In the right field the active time of the lubrication pulse can
be set.
