Fig.4-107: Mask "Lintab loading mask'
4.101.3 Description of the elements
Button Description
Select
Opens the selection dialog for loading a linea-
rization table from the file. The available data
must be located in directory <persistence-
path>\workspace\DATA\lintab\tog-
glelever.
4.102 Lintab select mask
4.102.1 Purpose
This mask is used to load available movement linearization tables.
4.102.2 Description of the mask
Button Load, loads the selectied linearization table.
