Delay times
Field Description
Forward delay
Field Pump on specifies the time that is waited between the start
of the Ejector forward movement and the activation of the hydraulic
pump.
Field Valve off determines the time that is waited between the end
of the Ejector forward movement and the closing of the control
valve in order to release the remaining pressure.
Backward delay
Field Pump on specifies the time that is waited between the start
of the Ejector backward movement and the activation of the hy-
draulic pump.
Field Valve off determines the time that is waited between the end
of the Ejector backward movement and the closing of the control
valve in order to release the remaining pressure.
Ramp setup mode
Field Description
Ramp setup mode forward
Ramp (pressure and velocity) in setup mode for ejector forward
movement is adjusted here.
Ramp setup mode back-
ward
Ramp (pressure and velocity) in setup mode for ejector backward
movement is adjusted here.
4.20 Cores
4.20.1 Purpose
Settings for the operating modes of the cores can be made in this mask.
4.20.2 Description of the mask
The activation and the operating mode of the core can be adjusted in the upper
section of the mask. Settings for activated cores can be made in the lower
section of the mask.
Description of the operating masks KePlast.HMI.KVB
© KEBA 2016
User's manual V3.0576
