Core general settings
Field Description
Override core safety
If this function is enabled, core movements can be made in setup
mode at any time.
Cores parallel to mold
Cores move parallel to mold movements if core mode in core mask
is set to 'During close' or 'During open'.
If the machine is equipped with only one hydraulic pump for the
mold- and core movement, both movements share the pump out-
put. A pump output to the core only happens as long as the mold
movement is active.
Parallel core movement
All cores that have the same mode in core mask move parallel to
each other. Only for modes 'Before close', 'After close', 'Before
open' and 'After open'.
If the machine is equipped with only one hydraulic pump for the
core movements, all parallel core movements share the pump
output. A pump output to a core only happens as long as the core
with the highest priority is active (see core priority settings on core
mask).
Maximum movement time
Field Description
Max. core 1 in time
The left field Actual displays the current time for core in move-
ment. The maximum permitted time until the core is in is specified
in field Limit. If this time is exceeded an alarm will be triggered
and the cycle is stopped. The difference between the two values
is shown in the right field Differ.
Max. core 1 out time
The left field Actual displays the current time for core out move-
ment. The maximum permitted time until the core is out is specified
in field Limit. If this time is exceeded an alarm will be triggered
and the cycle is stopped. The difference between the two values
is shown in the right field Differ.
Max. core 2 in time
The left field Actual displays the current time for core in move-
ment. The maximum permitted time until the core is in is specified
in field Limit. If this time is exceeded an alarm will be triggered
and the cycle is stopped. The difference between the two values
is shown in the right field Differ.
Max. core 2 out time
The left field Actual displays the current time for core out move-
ment. The maximum permitted time until the core is out is specified
in field Limit. If this time is exceeded an alarm will be triggered
and the cycle is stopped. The difference between the two values
is shown in the right field Differ.
4.22 Core setup - Tab2
4.22.1 Purpose
Additional settings for core movement can be made in this mask.
