Name Description
Connecting lines
Connections between the individual move-
ments are shown by black lines.
Sequences
The machine sequence is divided into sequen-
ces by colored bars on the left edge of the
mask. A legend about the sequences is dis-
played at the bottom edge of the mask.
4.78 Sequence - Safety conditions
WARNING!
The system (hardware and software) only meets category B according to
EN ISO 13849-1. Thus it is not intended for usage in safety-relevant control ap-
plications in the field of personal safety (e.g. emergency stop).
To implement potentially necessary safety-relevants control tasks, always use
additional external safety devices according to EN ISO 13849-1 that are intended
for the particular purpose and meet the necessary functional safety.
For further information see EN ISO 13849-1 and refer to chapter "EC directives
and standards" in the manuals for a list of norms applying to the product.
The safety notices for the installation and commissioning of the product can be
found in the user manuals of the components or in the system manual and must
be read and observed before installation or commissioning.
The user manual must be kept throughout the entire service life of the product.
4.78.1 Purpose
In this mask the necessary conditions for executing the movements of the ma-
chine sequence and their current state are displayed
4.78.2 Description of the mask
The necessary conditions for executing the movements are displayed in tab-
ular form. The left column displays the condition (e.g. "Core1Out"). The right
column displays the current state of the condition (True: condition has been
met, False: condition not met)
Only if all conditions have been fulfilled ('True'), the movement will be executed.
KePlast.HMI.KVB
Description of the operating masks
© KEBA 2016
User's manual V3.05 165
