Nozzle adjust
Field Description
Monitor time
Maximum time which is permitted for automatic nozzle adjustment.
If this time is exceeded an alarm will be raised.
Standstill
If the standstill time exceeds during automatic nozzle adjust with-
out any movement of the nozzle, an alarm will be raised.
Auto nozzle adjust
This button starts or stops the automatic nozzle adjustment.
Only allowed in Setup mode.
Maximum movement time
Field Description
Max. forward time
The left field Actual displays the current time for nozzle forward
movement. The maximum permitted time until the nozzle is for-
ward is specified in field Limit. If this time is exceeded an alarm
will be triggered and the cycle is stopped. The difference between
the two values is shown in the right field Differ.
Max. backward time
The left field Actual displays the current time for nozzle backward
movement. The maximum permitted time until the nozzle is back
is specified in field Limit. If this time is exceeded an alarm will be
triggered and the cycle is stopped. The difference between the two
values is shown in the right field Differ.
Max. purge time
The left field Actual displays the current time for auto purge. The
maximum permitted time for auto purge is specified in field Limit.
If this time is exceeded an alarm will be triggered and the cycle is
stopped. The difference between the two values is shown in the
right field Differ.
Movement start delay
Field Description
Forward delay The delay time for the nozzle forward movement is adjusted here.
Backward delay
The delay time for the nozzle backward movement is adjusted
here.
4.42 Nozzle Setup Advanced
4.42.1 Purpose
Additional parameters for the nozzle can be configured within this mask.
4.42.2 Description of the mask
For the nozzle movement the minimum profile outputs, maximum ramp set-
tings, pump and valve delay times and settings for mold height adjustment can
be set.
KePlast.HMI.KVB
Description of the operating masks
© KEBA 2016
User's manual V3.05 113
