4.22.2 Description of the mask
Besides general settings for the cores, maximum movement and movement
delay times as well as the constant outputs for the core movement in setup
mode can be set. Further overriding core safety and parallel movements for
cores can be configured in this mask.
Fig.4-25: Mask "Core Setup - Tab2"
4.22.3 Description of the elements
Core setup mode output
Field Description
Constant core in
Pressure and velocity output for the core in movement in setup
mode.
Constant core out
Pressure and velocity output for the core out movement in setup
mode.
Core movement start delay times
Field Description
Core in The delay time for the core in movement is adjusted here.
Core Out The delay time for the core out movement is adjusted here.
