Fig.4-58: Mask "Mold data"
4.54.3 Description of the elements
Mold data record
Field Description
Mold data Name of the currently loaded mold data record.
Drive
Name of the currently selected drive. The list
shows all available mold data records on the
selected drive.
Buttons
Field Description
Load
Loads the settings of the selected mold data
record. Existing SPC-recordings are deleted.
Save Opens a dialog for saving the actual mold data.
Delete Deletes the selected mold data record.
Find
Opens a dialog for searching mold data re-
cords.
Drive
Selects the target for saving and loading (Com-
pact Flash or USB storage medium, if connec-
ted) the mold data. The current selection is
displayed at the right upper corner of the mask.
Description of the operating masks KePlast.HMI.KVB
© KEBA 2016
User's manual V3.05134
